Sovema by MAC Curing Chamber
Sovema by MAC Curing Chamber
Precise Control Over the Curing Process
Precise Control Over the Curing Process
The Sovema by MAC Curing Chamber is designed to give the manufacturer enhanced control of the curing and drying process through custom tuned curing profiles. Enhanced control over the curing and drying process ensures an optimal bond between the active material to the grid. The air flow design and control package together allow for tighter, more consistent temperature control of the chamber interior. An emphasis on laminar air flow supplied from two sides results in even exposure to all plates ensuring excellent quality and consistency. Even at its maximum operating temperature of 121° C (250° F), a standard three inches of insulation between stainless steel walls maintain a cool ambient environment. During the drying process, a powered exhaust positioned at the bottom of the chamber forces out the most humid air first. Sealing up the chamber is a solid panel, insulated, weathered sealed, rubber, automatic door to keep desired conditions of the interior.
Choose Sovema by MAC for efficient, high quality curing solutions. (available in the Americas only
The Sovema by MAC Curing Chamber is designed to give the manufacturer enhanced control of the curing and drying process through custom tuned curing profiles. Enhanced control over the curing and drying process ensures an optimal bond between the active material to the grid. The air flow design and control package together allow for tighter, more consistent temperature control of the chamber interior. An emphasis on laminar air flow supplied from two sides results in even exposure to all plates ensuring excellent quality and consistency. Even at its maximum operating temperature of 121° C (250° F), a standard three inches of insulation between stainless steel walls maintain a cool ambient environment. During the drying process, a powered exhaust positioned at the bottom of the chamber forces out the most humid air first. Sealing up the chamber is a solid panel, insulated, weathered sealed, rubber, automatic door to keep desired conditions of the interior.
Choose Sovema by MAC for efficient, high quality curing solutions.
(available in the Americas only)
The MAC Advantage
- Available in gas or electric heat options
- Long life with high reliability track record
- Steam injection option available for tetrabasic curing
- Advanced control systems with easy to change curing formulas
- Power exhaust at bottom of the chamber force out most humid air first
- Custom sized to almost any customer specification from 4 to 160+ racks
- Main control stations available to control multiple chambers from one centralized point
- Each chamber is equipped with self-cleaning atomizers, or steam generators if higher temps are required
- Rear or top mounted heater designs
- Maximum operating temp of 121° C (250° F)
- Nearly ever facet is customizable including:
- Recirculation rate
- Exhaust rate
- Heat input
- Humidity controls
- Chamber size
- Chamber access
The MAC Advantage
- Available in gas or electric heat options
- Long life with high reliability track record
- Steam injection option available for tetrabasic curing
- Advanced control systems with easy to change curing formulas
- Power exhaust at bottom of the chamber force out most humid air first
- Custom sized to almost any customer specification from 4 to 160+ racks
- Main control stations available to control multiple chambers from one centralized point
- Each chamber is equipped with self-cleaning atomizers, or steam generators if higher temps are required
- Rear or top mounted heater designs
- Maximum operating temp of 121° C (250° F)
- Nearly ever facet is customizable including:
- Recirculation rate
- Exhaust rate
- Heat input
- Humidity controls
- Chamber size
- Chamber access
